PRODUCT

ENTERPRISE BRIEF INTRODUCTION

iPS Energy Storage BOX System

Application Scenarios:

Area Expanxion,Commercial Enterprise,& IDC data Center& Park Energy Storage,Commercial Buildings,Large Industrial,Mobile Energy Storage

Functions & Features:

  • Forced air cooling or Liquid cooling
  • Remote maintaining and monitoring
  • EMS Inside,multiple operations style
  • Multiple sets parallel connection surportable,
  • Power scope:50KW-1MW
  • Optional configurations(xxx hours)
  • Integrated transportation,simply installing
  • High aczoiling grade,multiple work environment acceptable
  • 100% DOD deep discharge,15 years serve life under standard work condition
  • High efficiency heat management system
  • Graded linkage protection and guarantee system safety

Parameter

PS600-04/100-230-W

DC Cell Parameter

Cell Type

LFP 3.2V/280Ah

Pack Configuration

1P52S/46kWh

Cell System Configuration

1P260S

Cell Voltage Range

728V~923V

Cell System Capacity

230kWh

Temperature Detecting

cell+copper bar

AC Parameter (on network)

Rated Power

100kW

Max Output Power

110kW

Rated Grid Voltage

380V

Allowable Grid Voltage

-15%~10%

Rated Grid Frequency

50Hz/60Hz

Allowing Grid Frequency Fluctuatioins

±5Hz

Power Factor

-1(lead)~1(lag)

AC Harmonic (THDi)

<3%(rated output power)

Connection Mode

Three phase three line/three phase four line

Full Power Chargeing & Discharge

Conversion Time

<25mS

AC Parameter (off network)

Rated Output Voltage

380V

Rated Output Power

100kW

Rated Output Frequency

50Hz/60Hz

AC Harmonic(THDu)

<3%(linear load)

Overload Capacity

1. 1 times long term(45℃),1.2 times 1min

System Parameter

Circulation Times

6000times

Converter Max Efficiency

99%

System Efficiency

>88%

Charge & Discharge Rate

≤0.5C

Protection

DC Input

Load switch+fuse

AC Output Protection

Breaker

Over Voltage Protection

DC TypelI/ AC Typell

Fire Control System

Aerosol/ perfluorohexanone/ water fire control (optional)

Convention Parameter

Dimention

1300×1300×2265mm

Incoming Mode

AC bottom incoming

Alloing Environment Temperature

-30℃~+60℃ (>50℃ derate)

Allowing Relative Humidity

0~100%

Max Elevation

4000m (>2000 m derate)

Weight

2800kg

Protection grade

P54

Cooling mode

water

Communication

Communication interface

RS485/Ethernet

Communication protocol

IEC61850/MODBUS-RTU/MODBUS-TCP



iPS Energy Storage BOX System
